Home /Rolair H15160K17 1.5 HP Single-Stage Horizontal Air Compressor - 60 Gallon
Rolair H15160K17 1.5 HP Single-Stage Horizontal Air Compressor - 60 Gallon

Product image is for reference only and may not match the exact selected configuration.

Rolair

Rolair H15160K17 1.5 HP Single-Stage Horizontal Air Compressor - 60 Gallon

MPN: H15160K17

$1,897.00
Direct Shipment from Manufacturer
Rolair H15160K17 — 1.5 HP Single-Stage Stationary Air Compressor The Rolair H15160K17 is a 1.5 HP, single-stage, single phase (230v) electric stationary air compressor mounted on a 60-gallon horizontal ASME air receiver tank.
Large items ship by LTL freight. Freight cost varies by destination and delivery requirements and will be calculated at checkout or confirmed before processing.
Manufacturer warranty included
Assembled to order (~4 weeks)
Questions? (727) 900-5977
Accepted Payment Methods:
Shipping Policy | Return Policy | Warranty Info

Rolair H15160K17 — 1.5 HP Single-Stage Stationary Air Compressor

The Rolair H15160K17 is a 1.5 HP, single-stage, single phase (230v) electric stationary air compressor mounted on a 60-gallon horizontal ASME air receiver tank. Delivering 6.9 CFM at 100 PSI, this unit is built for demanding shop and industrial applications.

Key Specifications

Horsepower 1.5 HP
Stage Single-Stage
Phase Single Phase (230V)
Tank Size 60 Gallons (Horizontal)
CFM Displaced 10.1 CFM @ 100 PSI
CFM Delivered 6.9 CFM @ 100 PSI
Motor Speed 1740 RPM, 60 Hz
Dimensions (L×W×H) 52" × 20" × 41"
Shipping Weight 285 lb.

Pump Features

  • Single-Stage cast-iron cylinders
  • Aluminum head and crankcase for faster heat dissipation
  • Ball bearings throughout
  • Splash lubricated with oil sight gauge
  • Bearing inserts on connecting rods
  • Swedish lamellar reed valves
  • Low RPMs for long life and trouble-free performance

Standard Equipment

  • Pressure switch with start/stop operation and on/off switch
  • Automatic unloading device for loadless starts
  • Heavy-duty brass shut-off valve
  • Pressure gauge (0-200 PSI)
  • ASME-approved safety relief valve
  • Multiple V-belt drive with totally enclosed steel belt guard
  • Intake filter/silencer with replaceable element

Optional Equipment

  • Automatic tank drain
  • Low oil shutdown
  • Vibration pads
  • Dual controls
  • Head unloader
  • Refrigerant air dryer

Ships from manufacturer in Hustisford, Wisconsin. Rolair compressors are backed by a 1-year warranty and a network of over 400 service centers nationwide.
